Prefab Agricultural Buildings

As a classification of mobile housing products, The Agricultural prefab house has been widely used in livestock and poultry sheds, barns, grain, animal feed and other agricultural materials storage. Due to the product mainly steel square tube and C section steel purlin as the skeleton of the product so there are certain limitations in the span and height of the single. But it also has the following advantages:

In factory design and production, the main structure is connected by bolts, standardized production, accurate component size, a small error.
Mechanized processing, component standards with interchangeability.
The material quality is light, easy to assemble and disassemble.
The manufacturing and installation cycle is short, and the number of rooms can be reduced or increased without changing any original materials during the turnover according to the needs of customers in the process of disassembly, which is convenient for transportation.
Beautiful and durable, the product life of more than 15 years, according to the cycle of maintenance and replacement, can extend the product life of more than 10 years. One-time investment, high reuse value, low comprehensive use cost.

Get a Quote

Product Parameters of Prefab Agricultural Buildings

Prefab T Type house Agricultural Buildings Cow shed Prefabricated Barn Horse Stable Technical Specification

No.+A2:D29	Sort	Name	Specification
1	Product Type	Degree of Standardization	custom-made product, design and manufacture according to clients requirement
2	Size	Length (m):	No limited, increase expansion joint when length more than 200m.
3		Width(m):	single span should be less than 12m, an arbitrary width could make by union spans
4		Heigth(m):	single floor≤5m, two or three floors, average height ≤4m
5		Roof slope:	slope is 1:10~1:5
6	Standard equipment	Ground channel	Galvanized steel panle compression, thickness is 0.8mm
7		Post	Inside post is steel square pipe, material is Q235, components surface make antirust process, and decorate with color steel compression parts.
8		Roof beam	roof truss consist of thin sharpe steel by welding, component surface make antirust process
9		Purlin	C or Z section steel, size from C120~C320, Z100~Z200
10		Wall beam	wall beam is Ctype steel or square pipe, material is Q235,component surface make antirust process
11		Floor	made of floor master beam, secondary beam and floor surface plate(plywood)
12		Wall & roof panel	EPS, rock cotton, fiber glass, PU Sandwich panels/ or steel sheet
13		door	Sliding door or rolling door
14		window	PVC sliding window, with steel screen.
15		Electrical accessories	Supply plan, design and construction according to relevant national norms(220V,50Hz, with lamp, switches and multi-function sockets.)
16		Water plumbing accessories	Supply plan, design and construction according to relevant national norms
17		Bracing	Steel angle, steel pipe, steel round.
18		Gutter	Steel sheet or galvanized steel sheet
19		Rainspout	PVC pipe
20		Accessories	Anchor bolt, high strengthen bolt, normal bolt, skylight panel, ventilators, etc.
21	Design technical data	Roof dead load	0.3KN/sqm
22		Roof live load	0.5KN/sqm
23		Floor dead load	0.5KN/sqm
24		Floor live load	2KN/sqm
25		Wind load	12degree,120km/h(strengthen the steel frame when the wind is bigger than this data)
26		Earthquake resistant intensity	8 degree
27		Used for temperature	Celsius: from -25 to+50 (change the design when the temperature is lower than Celsius -25)
28	Installation	Installation tools	electric drill, electric hammer, spanner, screwdriver, pulling rivet etc, house installation need electric power.
29	Installation	Installation efficiency	Four skilled labor one day can erect 40m2's house body
30	Transport	container	each 40ft container could load 130~150Sqm house body material

Advantages of Prefab Agricultural Buildings

Factory design and production, the main structure is connected by bolts, standardized production, accurate component size, small error
Mechanized processing, component standards with interchangeability
The material quality is light, easy to assemble and disassemble.
The manufacturing and installation cycle is short, and the number of rooms can be reduced or increased without changing any original materials during the turnover according to the needs of customers in the process of disassembly, which is convenient for transportation
Beautiful and durable, the product life of more than 15 years, according to the cycle of maintenance and replacement, can extend the product life of more than 10 years. One-time investment, high reuse value, low comprehensive use cost
